Place of Origin:
China
Brand Name:
HDPARTS
Model Number:
4JA1
4JA1 Diesel Engine Cylinder Liner 8-97176-693-0 8-94462-130-0 8-94110-144-0 For ISUZU
Specification
| Applicable models | 4JA1 |
| Type | Cylinder liner |
| Original number | 8-97176-693-0 8-94462-130-0 8-94110-144-0 |
| Warranty | 6 months |
| Engine Type | Diesel |
| Brand Name | HDPARTS |
| Condition | New |
| Size | OEM Size |
|
The inner surface of the cylinder sleeve is directly affected by the high-temperature and high-pressure gas, and always has high-speed sliding friction with the piston ring and piston skirt. The surface comes into contact with cooling water, causing severe thermal stress under large temperature differences and being corroded by cooling water. The lateral thrust of the piston on the cylinder liner not only intensifies its internal surface friction, but also causes it to bend. When the lateral thrust changes direction, the piston also impacts the cylinder liner. In addition, it is also subjected to significant installation preload.
The gas pressure causes tangential tensile stress and radial compressive stress on the cylinder wall, and the maximum stress on the inner surface is high-frequency pulsating stress.
Due to the significant thermal stress generated by the temperature difference between the inner and outer walls of the cylinder, compressive stress is generally generated on the inner surface, while tensile stress is present on the cooling surface. But at extremely high temperatures, the metal near the inner surface undergoes creep plastic deformation, and after cooling, residual tensile stress forms on the inner surface. This low-frequency stress caused by changes in starting and stopping can cause material fatigue.
The cylinder liner should have sufficient strength, stiffness, and heat resistance, as well as good wear resistance. There should be good lubrication and cooling during work. |
Product Description
Company Information
Guangzhou Star Mustang Construction Machinery Parts Co., Ltd. is a construction machinery engine parts company integrating research and development, agency, domestic and international sales and e-commerce.
At presentIt was the first one to enter the construction machinery parts market in 1995. It is located in the center of the world's largest industrial distribution center.
is supported by scientific research and development strength, new business philosophy, mature marketing team, development and sales of high quality excavator parts.
covers a wide range, and its products are characterized by high strength, high toughness, high temperature resistance, no deformation, high wear resistance, etc.
Including Hydraulics parts, Final Drives parts, Undercarriage parts, General consumable parts, Engine spare parts, and stuff like that which are high-qualified products.
The product matching different kinds of excavator spare parts, which caters to the current market demand for high.
Packaging & Shipping
Packaging material:Plastic, carton, wooden box
We get to start preparing the goods when we receive payment from you. (The goods will be sent between 48 hours to 72 hours if we have in stock. The goods will be sent before the delivery time and the sample will send to you for checking.)
