Place of Origin:
China
Brand Name:
HDPARTS
Model Number:
8PB1 10PB1
Contact Us
8PB1 10PB1 Diesel Engine Cylinder Liner 9-11261-063-0 For ISUZU
Specification
Causes and Prevention
Diesel engine cylinder pulling refers to the phenomenon of excessive wear, burrs, scratches, scratches, cracks, or bites on the working surface caused by the intense interaction between the piston components and the cylinder mating working surface (caused by friction). Cylinder pulling is the adhesive wear to varying degrees under lubrication conditions. When cylinder pulling is light, it causes damage to the cylinder liner and piston components, and in severe cases, it can cause a vicious engine damage accident of cylinder biting. When pulling the piston or connecting rod, it can damage the machine, Therefore, it is of great significance to analyze the formation mechanism of the diesel engine cylinder pulling fault, find out the early prediction and correct countermeasures, correctly manage and use the diesel engine, improve the reliability and extend the service life, and improve the management personnel's strain energy for troubleshooting. Reasonable use and attention to maintenance (regular inspection) can also reduce the diesel engine cylinder pulling fault
| Applicable models | 8PB1 10PB1 |
| Type | Cylinder liner |
| Original number | 9-11261-063-0 |
| Warranty | 6 months |
| Engine Type | Diesel |
| Brand Name | HDPARTS |
| Condition | New |
| Size | OEM Size |
1. Cylinder pulling phenomenon:
The mechanism of cylinder pulling damage is mostly due to local damage to the lubricating oil film at the sliding part. At this time, two relatively moving surface protrusions first come into contact with metal, and then a small "melting" phenomenon occurs locally. The melting part is torn apart due to the relative movement of the components. During this process, the metal surface forms a hardened layer, and when the hardened layer is damaged, The metal abrasive particles generated will become the abrasive material that intensifies surface wear. In a short period of time during the so-called "melting wear", uneven wear marks parallel to the centerline of the cylinder appear on the surface of the piston and cylinder liner, which is the phenomenon of cylinder pulling. In severe cases, the sliding parts are completely adhered or stuck, and even cracks may occur in the weak parts of the two surfaces, causing damage to the parts, namely cylinder biting. Therefore, the fundamental cause of cylinder pulling is melting wear.
Product Description
,
Company Information
Guangzhou Star Mustang Construction Machinery Parts Co., Ltd. is a construction machinery engine parts company integrating research and development, agency, domestic and international sales and e-commerce.
At presentIt was the first one to enter the construction machinery parts market in 1995. It is located in the center of the world's largest industrial distribution center.
is supported by scientific research and development strength, new business philosophy, mature marketing team, development and sales of high quality excavator parts.
covers a wide range, and its products are characterized by high strength, high toughness, high temperature resistance, no deformation, high wear resistance, etc.
Including Hydraulics parts, Final Drives parts, Undercarriage parts, General consumable parts, Engine spare parts, and stuff like that which are high-qualified products.
The product matching different kinds of excavator spare parts, which caters to the current market demand for high.
Packaging & Shipping
Packaging material:Plastic, carton, wooden box
We get to start preparing the goods when we receive payment from you. (The goods will be sent between 48 hours to 72 hours if we have in stock. The goods will be sent before the delivery time and the sample will send to you for checking.)
Packaging & Shipping
